Case 410 Series III
Browse All Case or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.27 ft in (3130 mm) |
| Width Over Tires | 4.93 ft in (1500 mm) |
| Ground Clearance | 8.35 in (212 mm) |
| Height To Top Of Cab | 6.57 ft in (2000 mm) |
| Wheelbase | 3.45 ft in (1050 mm) |
| Length W/O Bucket | 8.17 ft in (2490 mm) |
| Clearance At Max Lift And Dump | 7.52 ft in (2290 mm) |
| Reach At Max Lift And Dump | 23.63 in (600 mm) |
| Turning Radius From Center - Machine Rear | 54 in (1371.6 mm) |
| Turning Radius From Center - Inc Bucket | 73.41 in (1864.36 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2239 |
| Engine Model | 422T/M3 diesel Tier III certified |
| Gross Power | 60.4 hp (45 kw) |
| Net Power | 56.4 hp (42 kw) |
| Power Measured @ | 2900 rpm |
| Aspiration | Turbocharged |
| Displacement | 134.3 cu in (2.2 L) |
Operational
| Operational Weight | 5430 lb (2463 kg) |
| Fuel Capacity | 22.1 gal (83.3 L) |
| Cooling System Fluid Capacity | 3.1 gal (11.5 L) |
| Engine Oil Fluid Capacity | 2.8 gal (10.5 L) |
| Max Speed | 6.5 mph (10.5 km/h) |
| Hydraulic System Fluid Capacity | 13.3 gal (50 L) |
| Chain Box Fluid Capacity - Each Side | 2.1 gal (7.6 L) |
| Operating Speed | 6.5 mph (10.5 km/h) |
| Tire Size | 10.00 x 16.5 8 ply |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
Loader
| Breakout Force | 3751 lb (1701.5 kg) |
| Operating Load Rating | 1501.4 lb (681 kg) |
| Tipping Angle | 3000.5 degrees |
| Bucket Capacity | 0.5 yd3 (0.4 m3) |
Hydraulic
| Pump Type | Gear |
| Pump Flow Capacity | 19.5 gal/min (73.8 L/min) |
| Relief Valve Pressure | 3050 psi (21029 kPa) |
