Hyundai HSL400T
Browse All Hyundai or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 8.77 ft in (2673 mm) |
| Width Over Tires | 2.98 ft in (908 mm) |
| Ground Clearance | 6.74 in (171 mm) |
| Height To Top Of Cab | 5.96 ft in (1814 mm) |
| Wheelbase | 2.76 ft in (840 mm) |
| Length W/O Bucket | 6.96 ft in (2121 mm) |
| Clearance At Max Lift And Dump | 5.76 ft in (1753 mm) |
| Reach At Max Lift And Dump | 14.49 in (368 mm) |
| Turning Radius From Center - Machine Rear | 48 in (1219 mm) |
| Turning Radius From Center - Inc Bucket | 60.2 in (1529 mm) |
Engine
| Engine Make | 2334 |
| Engine Model | D722B |
| Gross Power | 19.8 hp (14.8 kw) |
| Net Power | 15.8 hp (11.8 kw) |
| Power Measured @ | 3100 rpm |
Operational
| Operational Weight | 3000.5 lb (1361 kg) |
| Fuel Capacity | 14.6 gal (55 L) |
| Hydraulic System Fluid Capacity | 11.4 gal (42.8 L) |
| Max Speed | 5.1 mph (8.1 km/h) |
| Tire Size | 5.90x15 |
Loader
| Operating Load Rating | 850 lb (385.6 kg) |
| Tipping Angle | 1799 degrees |
| Bucket Capacity | 0.3 yd3 (0.2 m3) |
Hydraulic
| Pump Flow Capacity | 8.1 gal/min (30.3 L/min) |
| Relief Valve Pressure | 2100 psi (14479 kPa) |
