John Deere 125
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 9.9 ft in (3016 mm) |
| Width Over Tires | 4.93 ft in (1502 mm) |
| Ground Clearance | 7 in (178 mm) |
| Height To Top Of Cab | 6.9 ft in (2102 mm) |
| Wheelbase | 2.92 ft in (889 mm) |
| Length W/O Bucket | 7.52 ft in (2292 mm) |
| Clearance At Max Lift And Dump | 6.47 ft in (1971 mm) |
| Reach At Max Lift And Dump | 19.5 in (495 mm) |
| Turning Radius From Center - Machine Rear | 51.25 in (1306 mm) |
| Turning Radius From Center - Inc Bucket | 51.25 in (1306 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | C190 |
| Net Power | 40 hp (29.9 kw) |
| Power Measured @ | 2800 rpm |
| Displacement | 119 cu in (2 L) |
Operational
| Operational Weight | 5470 lb (2481 kg) |
| Fuel Capacity | 15 gal (56.8 L) |
| Cooling System Fluid Capacity | 3.1 gal (11.4 L) |
| Hydraulic System Fluid Capacity | 18 gal (68 L) |
| Max Speed | 6.1 mph (9.8 km/h) |
| Operating Speed | 6.1 mph (9.8 km/h) |
| Tire Size | 10-16.5,6PR flotation |
| Operating Voltage | 12 V |
Loader
| Operating Load Rating | 1410 lb (640 kg) |
| Tipping Angle | 2820 degrees |
| Bucket Capacity | 0.5 yd3 (0.4 m3) |
Hydraulic
| Pump Type | Open-center |
| Pump Flow Capacity | 15 gal/min (56.8 L/min) |
| Relief Valve Pressure | 2000 psi (137.8 kPa) |
