John Deere 90
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 8.51 ft in (2591 mm) |
| Width Over Tires | 3.8 ft in (1156 mm) |
| Ground Clearance | 6.75 in (171 mm) |
| Height To Top Of Cab | 6.17 ft in (1880 mm) |
| Wheelbase | 2.57 ft in (781 mm) |
| Length W/O Bucket | 6.67 ft in (2032 mm) |
| Clearance At Max Lift And Dump | 6.09 ft in (1854 mm) |
| Reach At Max Lift And Dump | 125 in (3175 mm) |
| Turning Radius From Center - Machine Rear | 47 in (1194 mm) |
| Turning Radius From Center - Inc Bucket | 47 in (1194 mm) |
Engine
| Number Of Cylinders | 2 |
| Engine Make | 2370 |
| Net Power | 23 hp (17.2 kw) |
| Power Measured @ | 3000 rpm |
| Displacement | 60 cu in (1 L) |
Operational
| Operational Weight | 2825 lb (1281 kg) |
| Fuel Capacity | 7.2 gal (27 L) |
| Hydraulic System Fluid Capacity | 11 gal (41.8 L) |
| Max Speed | 5 mph (8 km/h) |
| Operating Speed | 5 mph (8 km/h) |
| Tire Size | 8.50-15 |
| Operating Voltage | 12 V |
Loader
| Operating Load Rating | 700 lb (318 kg) |
| Tipping Angle | 1400 degrees |
| Bucket Capacity | 0.4 yd3 (0.3 m3) |
Hydraulic
| Pump Type | Open-center |
| Pump Flow Capacity | 7.5 gal/min (28.4 L/min) |
| Relief Valve Pressure | 1750 psi (12065.9 kPa) |
