John Deere 317
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 10.49 ft in (3195 mm) |
| Width Over Tires | 5.35 ft in (1628 mm) |
| Ground Clearance | 8.19 in (208 mm) |
| Height To Top Of Cab | 6.29 ft in (1915 mm) |
| Wheelbase | 3.53 ft in (1074 mm) |
| Length W/O Bucket | 8.51 ft in (2591 mm) |
| Clearance At Max Lift And Dump | 7.4 ft in (2255 mm) |
| Reach At Max Lift And Dump | 29.1 in (739 mm) |
| Turning Radius From Center - Inc Bucket | 78.9 in (2004 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4042T |
| Gross Power | 61 hp (45.5 kw) |
| Net Power | 57 hp (42.6 kw) |
| Power Measured @ | 2800 rpm |
| Aspiration | Turbocharged |
| Displacement | 149 cu in (2.5 L) |
Operational
| Operational Weight | 6300 lb (2857.7 kg) |
| Fuel Capacity | 16 gal (60.6 L) |
| Max Speed | 6.8 mph (11 km/h) |
| Tire Size | 10x16.5 8PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 amps |
Loader
| Breakout Force | 5500 lb (2494.8 kg) |
| Operating Load Rating | 1750 lb (793.8 kg) |
| Tipping Angle | 3700 degrees |
| Bucket Capacity | 0.6 yd3 (0.5 m3) |
Hydraulic
| Pump Flow Capacity | 17 gal/min (64 L/min) |
| Relief Valve Pressure | 3450 psi (23786.9 kPa) |
