JCB 524-50
Browse All JCB or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 12.8 ft in (3900 mm) |
| Ground Clearance | 1.09 ft in (330 mm) |
| Width Over Tires | 6.57 ft in (2000 mm) |
| Overall Height | 6.89 ft in (2100 mm) |
| Wheelbase | 7.55 ft in (2300 mm) |
| Turning Radius Outside Tires | 9.85 ft in (3000 mm) |
Lift
| Max Lift Height | 16.41 ft in (5000 mm) |
| Max Forward Reach | 9.52 ft in (2900 mm) |
| Max Load At Max Reach | 2750 lb (1247.38 kg) |
| Max Load At Max Height | 5000 lb (2267.97 kg) |
| Max Lift Capacity | 5000 lb (2267.97 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2257 |
| Gross Power | 83 hp (61.9 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 223 lb ft (302.4 Nm) |
| Torque Measured @ | 1400 rpm |
| Displacement | 256.3 cu in (4.2 L) |
| Aspiration | naturally aspirated |
Operational
| Operating Weight | 12125 lb (5499.9 kg) |
| Fuel Capacity | 19.9 gal (75 L) |
| Hydraulic System Fluid Capacity | 18.5 gal (70 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
| Tire Size | 12.5/80 x 18 |
Transmission
| Transmission Type | Hydrostatic 2 speed |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 18.7 mph (30 km/h) |
| Max Speed - Reverse | 18.7 mph (30 km/h) |
Hydraulic
| Pump Flow Capacity | 15.9 gal/min (60 L/min) |
| Relief Valve Pressure | 3626 psi (25000.4 kPa) |
