Dynapac CA150P (BRAZIL)
Browse All Dynapac or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 191.78 in (4871 mm) |
| Overall Width | 4.5 ft in (1371.6 mm) |
| Height To Top Of Cab | 6.73 ft in (2051 mm) |
| Wheelbase | 100.2 in (2545 mm) |
| Ground Clearance | 13.47 in (342 mm) |
| Height With Rops | 9.41 ft in (2867 mm) |
| Gradeability | 40 % |
| Overhang Front | 0.29 ft in (88 mm) |
| Overhang Rear | 0.29 ft in (88 mm) |
| Turning Radius - Inside | 9.09 ft in (2770 mm) |
| Turning Radius - Outside | 16 ft in (4876.8 mm) |
| Height With Out Rops | 9.41 ft in (2867 mm) |
| Curb Clearance | 16.42 in (417 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | Cummins |
| Engine Model | QSB3.3 |
| Engine Type | Water cooled turbo Diesel |
| Gross Power | 80.5 hp (60 kw) |
| Power Measured @ | 2200 rpm |
Operational
| Operating Weight Rops | 16314.3 lb (7400 kg) |
| Operating Weight | 19400.7 lb (8800 kg) |
| Fuel Capacity | 225 gal (851.8 L) |
| Max Speed | 7.5 mph (12.1 km/h) |
| Tire Size | 420-70B24 |
Drum
| Drum Thickness | 0.9 in (22 mm) |
| Drum Width | 66.2 in (1680 mm) |
| Drum Diameter | 48 in (1219 mm) |
| Pad Surface Area | 84 in2 (542 cm2) |
| Nominal Amplitude - High | 0.1 in (1.7 mm) |
| Nominal Amplitude - Low | 0.1 in (0.9 mm) |
| Centrifugal Force - High | 40690.5 lb (181 kN) |
| Centrifugal Force - Low | 39116.8 lb (174 kN) |
