Caterpillar 920
Browse All Caterpillar or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.09 ft in (2770 mm) |
| Bucket Capacity - Heaped | 1.2 yd3 (0.91 m3) |
| Bucket Width | 8.01 ft in (2440 mm) |
| Breakout Force | 8020 lb (8020 -) |
Dimensions
| Length With Bucket On Ground | 18.71 ft in (5700 mm) |
| Width Over Tires | _ - (2700 mm) |
| Height To Top Of Cab | 10.33 ft in (3148.59 mm) |
| Hinge Pin - Max Height | _ - (3753 mm) |
| Reach At Max Lift And Dump | 2.43 ft in (740 mm) |
Engine
| Engine Model | 3304 |
| Net Power | 80 hp (59.7 kw) |
| Displacement | 427.2 cu in (7 L) |
Operational
| Operating Weight | 18607.1 lb (8440 kg) |
| Fuel Capacity | 39.1 gal (148 L) |
| Hydraulic System Fluid Capacity | 19.6 gal (74 L) |
| Static Tipping Weight | 29519.9 lb (13390 kg) |
| Tire Size | 15.5-25 12 PR (L-2) |
Transmission
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 27.3 mph (43.8 km/h) |
| Max Speed - Reverse | 14.5 mph (23.2 km/h) |
Hydraulic System
| Raise Time | 6 sec |
| Dump Time | 1.2 sec |
| Lower Time | 3 sec |
