Kawasaki 60ZII
Browse All Kawasaki or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.68 ft in (2645 mm) |
| Bucket Capacity - Heaped | 2.1 yd3 (1.6 m3) |
| Bucket Capacity - Struck | 1.84 yd3 (1.4 m3) |
| Bucket Width | 8.04 ft in (2450 mm) |
| Breakout Force | 17200 lb (76.51 kN) |
Dimensions
| Ground Clearance | 1.25 ft in (380 mm) |
| Length With Bucket On Ground | 20.63 ft in (6285 mm) |
| Width Over Tires | 7.4 ft in (2255 mm) |
| Height To Top Of Cab | 9.96 ft in (3035 mm) |
| Wheelbase | 8.7 ft in (2650 mm) |
| Hinge Pin - Max Height | 11.41 ft in (3475 mm) |
| Reach At Max Lift And Dump | 3.56 ft in (1085 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2353 |
| Engine Model | 6BD1 |
| Net Power | 103 hp (76.9 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 353 cu in (5.8 L) |
| Aspiration | natural |
Operational
| Operating Weight | 18760 lb (8509.4 kg) |
| Fuel Capacity | 46.3 gal (175 L) |
| Hydraulic System Fluid Capacity | 23.8 gal (90 L) |
| Engine Oil Fluid Capacity | 2.7 gal (10 L) |
| Cooling System Fluid Capacity | 5.9 gal (22 L) |
| Transmission Fluid Capacity | 6.4 gal (24 L) |
| Front Axle/Diff Fluid Capacity | 5.3 gal (20 L) |
| Rear Axle/Diff Fluid Capacity | 5.3 gal (20 L) |
| Static Tipping Weight | 13130 lb (5955.7 kg) |
| Turning Radius | 17.6 ft in (5350 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 40 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 15.5-25-12PR (L2) |
Transmission
| Transmission Type | full power shift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 20.8 mph (33.5 km/h) |
| Max Speed - Reverse | 20.8 mph (33.5 km/h) |
Hydraulic System
| Relief Valve Setting | 3000 psi (20684.3 kPa) |
| Pump Flow Capacity | 25 gal/min (94.7 L/min) |
| Raise Time | 6 sec |
| Dump Time | 1 sec |
| Lower Time | 2.8 sec |
| Pump Type | gear type |
