Komatsu WA115PT-3
Browse All Komatsu or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.11 ft in (2775 mm) |
| Bucket Capacity - Heaped | 1.71 yd3 (1.3 m3) |
| Bucket Width | 7.55 ft in (2300 mm) |
| Breakout Force | 16478.5 lb (73.3 kN) |
Dimensions
| Ground Clearance | 1.25 ft in (378 mm) |
| Length With Bucket On Ground | 19.61 ft in (5975 mm) |
| Width Over Tires | 7.22 ft in (2200 mm) |
| Height To Top Of Cab | 9.88 ft in (3010 mm) |
| Wheelbase | 8.04 ft in (2450 mm) |
| Hinge Pin - Max Height | 11.8 ft in (3595 mm) |
| Reach At Max Lift And Dump | 2.68 ft in (815 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2238 |
| Engine Model | S4D 106-1HC |
| Gross Power | 87 hp (64.9 kw) |
| Max Torque | 270 lb ft (366 Nm) |
| Displacement | 269.3 cu in (4.5 L) |
| Aspiration | Turbocharger |
Operational
| Operating Weight | 16435.5 lb (7455 kg) |
| Fuel Capacity | 31.8 gal (120 L) |
| Hydraulic System Fluid Capacity | 22.5 gal (85 L) |
| Engine Oil Fluid Capacity | 3.7 gal (14 L) |
| Cooling System Fluid Capacity | 4 gal (15 L) |
| Transmission Fluid Capacity | 0.5 gal (1.6 L) |
| Front Axle/Diff Fluid Capacity | 1.2 gal (4.5 L) |
| Rear Axle/Diff Fluid Capacity | 1.2 gal (4.5 L) |
| Static Tipping Weight | 13371.1 lb (6065 kg) |
| Turning Radius | 14.9 ft in (4520 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 80 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 455/70 R24 SPT 9 |
Transmission
| Transmission Type | Hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 12.5 mph (20 km/h) |
| Max Speed - Reverse | 12.5 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 3045.8 psi (21000 kPa) |
| Pump Flow Capacity | 30.4 gal/min (115 L/min) |
| Raise Time | 4.9 sec |
| Dump Time | 1.5 sec |
| Lower Time | 3.7 sec |
| Pump Type | closed hydraulic system |
