Komatsu WA80-3
Browse All Komatsu or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.04 ft in (2450 mm) |
| Bucket Capacity - Struck | 0.92 yd3 (0.7 m3) |
| Bucket Capacity - Heaped | 1.18 yd3 (0.9 m3) |
Dimensions
| Ground Clearance | 1.09 ft in (330 mm) |
| Length With Bucket On Ground | 17.31 ft in (5275 mm) |
| Width Over Tires | 6.27 ft in (1910 mm) |
| Height To Top Of Cab | 9.36 ft in (2850 mm) |
| Wheelbase | 7.39 ft in (2250 mm) |
| Hinge Pin - Max Height | 10.19 ft in (3105 mm) |
| Reach At Max Lift And Dump | 2.91 ft in (885 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2238 |
| Engine Model | 4D102E |
| Gross Power | 59.1 hp (44 kw) |
| Power Measured @ | 1850 rpm |
| Displacement | 239.3 cu in (4 L) |
Operational
| Fuel Capacity | 19.9 gal (75 L) |
| Tire Size | 17.5/65-20 |
Transmission
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 19.9 mph (32 km/h) |
| Max Speed - Reverse | 19.9 mph (32 km/h) |
