Komatsu WF350-3
Browse All Komatsu or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 10.08 ft in (3070 mm) |
| Bucket Width | 9.6 ft in (2925 mm) |
Dimensions
| Ground Clearance | 1.48 ft in (450 mm) |
| Length With Bucket On Ground | 26.32 ft in (8020 mm) |
| Width Over Tires | 9.34 ft in (2845 mm) |
| Height To Top Of Cab | 11.08 ft in (3375 mm) |
| Wheelbase | 10.5 ft in (3200 mm) |
| Hinge Pin - Max Height | 13.42 ft in (4090 mm) |
| Reach At Max Lift And Dump | 3.68 ft in (1120 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | SA6D108E |
| Displacement | 436.4 cu in (7.2 L) |
Operational
| Operating Weight | 42218.6 lb (19150 kg) |
| Fuel Capacity | 75.9 gal (287 L) |
| Turning Radius | 22.1 ft in (6730 mm) |
Transmission
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 18 mph (28.9 km/h) |
| Max Speed - Reverse | 18.1 mph (29.1 km/h) |
