Ingersoll Rand PF6110
Browse All Ingersoll Rand or Asphalt Paver Models
Contents:
Dimensions
| Length W/ Screed | 17.17 ft in (5232.4 mm) |
| Transport Width | 9.84 ft in (2997.2 mm) |
| Transport Height | 12.5 ft in (3810 mm) |
| Track Width | 19 in (482.6 mm) |
| Width W/ Hopper Open | 10.75 ft in (3276.6 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSB 6.7 Tier 3 |
| Net Power | 205 hp (152.9 kw) |
| Power Measured @ | 1800 rpm |
Operational
| Operating Weight W/O Screed | 40066.9 lb (18174 kg) |
| Operating Weight W/ Screed | 44595.2 lb (20228 kg) |
| Fuel Capacity | 80 gal (302.8 L) |
| Hydraulic System Fluid Capacity | 62.6 gal (236.6 L) |
Hopper/Paver
| Hopper Capacity | 8.6 lb (6.6 kg) |
| Paving Width - Std | 10.1 ft in (3050 mm) |
| Paving Width - Max | 26 ft in (7920 mm) |
| Paving Thickness - Max | 12 in (304.8 mm) |
| Paving Speed - Max | 246.1 ft/min (75 m/min) |
| Travel Speed - Max | 10.1 mph (16.1 km/h) |
| Auger Diameter | 17 in (431.8 mm) |
