Kobelco SK210LC-9
Browse All Kobelco or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Vertical Wall Digging Depth | 0.02 ft in (5.57 mm) |
| Horizontal Digging Stroke - Ground Level | 0.02 ft in (4.08 mm) |
| Boom/Stick Option (Hex) 1 | 7'10"{2.4m} |
| Max Digging Reach On Ground | 0.04 ft in (9.42 mm) |
| Min Dumping Clearance | 0.01 ft in (2.98 mm) |
| Max Digging Reach | 0.04 ft in (9.42 mm) |
| Max Dumping Clearance | 0.03 ft in (6.68 mm) |
Boom/Stick Option (Hex) 2
| Max Vertical Wall Digging Depth | 0.02 ft in (6.1 mm) |
| Max Digging Depth | 0.03 ft in (6.7 mm) |
| Max Dumping Clearance | 0.03 ft in (6.91 mm) |
| Min Dumping Clearance | 22.68 ft in (6.91 m) |
| Horizontal Digging Stroke - Ground | 0.02 ft in (5.27 mm) |
| Boom/Stick Option (Hex) 2 | 9'8"{2.94m} |
| Max Digging Reach | 0.04 ft in (9.9 mm) |
| Minimum Swing Radius | 0.14 in (3.54 mm) |
| Max Digging Reach On Ground | 0.04 ft in (9.73 mm) |
Boom/Stick Option (Hex) 3
| Max Vertical Wall Digging Depth | 0.03 ft in (6.47 mm) |
| Max Digging Depth | 0.03 ft in (7.26 mm) |
| Max Dumping Clearance | 0.03 ft in (6.97 mm) |
| Boom/Stick Option (Hex) 3 | Arm 11'6"{3.50m} |
| Max Digging Reach | 0.04 ft in (10.34 mm) |
| Max Digging Reach On Ground | 0.04 ft in (10.17 mm) |
| Maximum Dig Radius | 0.14 in (3.48 mm) |
| Min Dumping Clearance | 0.01 ft in (1.87 mm) |
Dimensions
| Ground Clearance | 1.48 ft in (450 mm) |
| Height To Top Of Cab | 10.11 ft in (3080 mm) |
| Tail Swing Radius | 9.39 ft in (2860 mm) |
| Track Gauge | 7.85 ft in (2390 mm) |
| Overall Length | 31.6 ft in (9630 mm) |
| Overall Width | 125.2 in (3180 mm) |
| Shoe Width | 2.63 ft in (800 mm) |
| Overall Width Of Superstructure | 8.9 ft in (2710 mm) |
| Gradeability | 70 % |
Undercarriage
| Drawbar Pull | 51500 lb (229.09 kN) |
Engine
| Number Of Cylinders | 4 |
| Engine Model | HINO J05E-TI |
| Net Power | 92.8 hp (69.3 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 472 lb ft (640 Nm) |
| Displacement | 312.7 cu in (5.2 L) |
| Torque Measured @ | 1600 rpm |
| Bore | 4.5 in (112 mm) |
| Stroke | 5.2 in (130 mm) |
Operational
| Fuel Capacity | 97.8 gal (370 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Hydraulic System Fluid Capacity | 34.4 gal (130 L) |
| Engine Oil Capacity | 5.5 gal (20.5 L) |
| Swing Drive Fluid Capacity | 0.8 gal (3 L) |
| Hydraulic Pump Flow Capacity | 60.8 gal/min (230 L/min) |
Swing Mechanism
| Swing Speed | 11 rpm |
Hydraulic System
| Max. Discharge Flow | 116.3 gal/min (440 L/min) |
| Hydraulic System Type | Two variable displacement pumps + 1 gear pump |
| Travel Circuit | 4970 psi (34267 kPa) |
| Swing Circuit | 4210 psi (29027 kPa) |
