Caterpillar 428 Series II
Browse All Caterpillar or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 11.44 ft in (3486 mm) |
| Reach From Swivel - Std | 17.65 ft in (5377 mm) |
| Dig Depth - Std | 15.59 ft in (4750 mm) |
| Bucket Dig Force - Std | 10438 lb (4734.6 kg) |
| Bucket Dig Force - Ext | 10258 lb (4652.96 kg) |
| Reach From Swivel - Ext | 21.75 ft in (6629 mm) |
| Load At Max Lift - Std | 3836.05 lb (1740 kg) |
| Load At Max Lift - Ext | 2116.44 lb (960 kg) |
| Dig Depth - Ext | 19.68 ft in (5998 mm) |
| Load Height - Ext | 13.76 ft in (4192 mm) |
Dimensions
| Transport Length | 18.66 ft in (5685 mm) |
| Transport Width | 7.9 ft in (2406 mm) |
| Transport Height | 11.73 ft in (3574 mm) |
| Wheelbase | 6.89 ft in (2100 mm) |
| Ground Clearance | 1.05 ft in (320 mm) |
| Height To Top Of Suspended Cab | 9.11 ft in (2776 mm) |
Loader
| Clearance At Max Dump Height | 8.68 ft in (2643 mm) |
| Reach At Max Dump Height | 2.77 ft in (844 mm) |
| Dig Depth | 3.9 in (99 mm) |
| Lift Capacity At Full Height | 5249.21 lb (2381 kg) |
| Bucket Capacity | 1.31 yd3 (1 m3) |
| Bucket Width | 94.34 in (2396 mm) |
| Bucket Breakout Force | 8048.17 lb (35.8 kN) |
Engine
| Engine Make | 2351 |
| Engine Model | 4.236 |
| Net Power | 69.8 hp (52 kw) |
| Gross Power | 75.1 hp (56 kw) |
| Displacement | 235.6 cu in (3.9 L) |
Operational
| Operating Weight 2wd | 15747.7 lb (7143 kg) |
| Turning Radius | 12.9 ft in (3914 mm) |
| Tire Size Front - 2wd / 4wd | 9-16 10PR / 10.5-20 10PR |
| Rear Tires Size 2wd/4wd | 16.9-28 10 PR |
Transmission
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 18.3 mph (29.4 km/h) |
| Max Speed Reverse | 18.4 mph (29.6 km/h) |
Hydraulic
| Pump Flow Capacity | 28.6 gal/min (108 L/min) |
| Relief Valve Pressure | 2700 psi (18615.9 kPa) |
