Manitou MHT 10230
Browse All Manitou or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 22.11 ft in (6739.13 mm) |
| Ground Clearance | 1.7 ft in (518.16 mm) |
| Width Over Tires | 9.4 ft in (2865.12 mm) |
| Overall Height | 10 ft in (3048 mm) |
| Wheelbase | 12.1 ft in (3688.08 mm) |
| Weight | 64595.44 lb (29300 kg) |
| Turning Radius Outside Tires | 17.9 ft in (5455.92 mm) |
Lift
| Max Lift Height | 31.7 ft in (9662.16 mm) |
| Max Forward Reach | 19 ft in (5791.2 mm) |
| Max Lift Capacity | 50706.32 lb (23000 kg) |
| Boom Extension Time - Unladen | 18 sec |
| Lowering Time - Unladen | 37 sec |
| Lifting Time - Unladen | 42 sec |
| Dump | 11 sec |
| Crowd | 11 sec |
| Boom Retraction Time - Unladen | 18 sec |
Engine
| Fuel | Diesel |
| Emission Tier Level | Stage IV / Tier 4 Final |
| Injection System | Direct |
| Number Of Cylinders | 4 |
| Engine Make | Mercedes |
| Engine Type | OM 934 LA. E4-3 |
| Gross Power | 176 hp (131.3 kw) |
| Cooling System | Water |
| Max Torque | 553.2 lb ft (750 Nm) |
| Displacement | 18990.6 cu in (311.2 L) |
| System Voltage | 24 V |
Operational
| Hydraulic System Fluid Capacity | 76.6 gal (290 L) |
| Drawbar Pull | 41589 lb (18864.5 kg) |
Transmission
| Number Of Wheels Front | 2 |
| Number Of Wheels Rear | 2 |
| Driving Position Noise Levels | 80 dB |
| Environmental Noise Levels | 107 dB |
| Vibration Affecting Hands/Arms | 2.5 sec |
| Transmission Type | Hydrostatic |
Hydraulic
| Pressure | 5076.4 psi (35000 kPa) |
