Tata Hitachi TWL3036
Browse All Tata Hitachi or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.18 ft in (2796 mm) |
| Bucket Capacity - Heaped | 2.62 yd3 (2 m3) |
| Bucket Capacity - Struck | 2.22 yd3 (1.69 m3) |
| Bucket Width | 8.5 ft in (2590 mm) |
| Breakout Force | 25573.6 lb (25573.6 -) |
Dimensions
| Ground Clearance | 0.99 ft in (300 mm) |
| Length With Bucket On Ground | 24.79 ft in (7556 mm) |
| Width Over Tires | 7.93 ft in (2416 mm) |
| Height To Top Of Cab | 10.46 ft in (3186 mm) |
| Wheelbase | 9.32 ft in (2840 mm) |
| Hinge Pin - Max Height | 12.18 ft in (3710 mm) |
| Reach At Max Lift And Dump | 4.53 ft in (1379 mm) |
Engine
| Engine Model | TATA 697TC |
| Net Power | 135 hp (100.7 kw) |
| Gross Power | 125 hp (93.3 kw) |
| Max Torque | 441 lb ft (598 Nm) |
| Displacement | 346.4 cu in (5.7 L) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 34733.9 lb (15755 kg) |
| Fuel Capacity | 50.2 gal (190 L) |
| Hydraulic System Fluid Capacity | 37 gal (140 L) |
| Engine Oil Fluid Capacity | 4.8 gal (18 L) |
| Cooling System Fluid Capacity | 6.1 gal (23 L) |
| Transmission Fluid Capacity | 5.3 gal (20 L) |
| Front Axle/Diff Fluid Capacity | 6.4 gal (24 L) |
| Rear Axle/Diff Fluid Capacity | 6.4 gal (24 L) |
| Static Tipping Weight | 26698 lb (12110 kg) |
| Turning Radius | 19.6 ft in (5967 mm) |
| Operating Voltage | 24 V |
| Rear Axle Oscillation | 28 degrees |
| Tire Size | 14x25.2 PR |
Transmission
| Transmission Type | ZR Ergo Power Transmission 3WG 130 |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 15.3 mph (24.5 km/h) |
| Max Speed - Reverse | 11.5 mph (18.4 km/h) |
Hydraulic System
| Relief Valve Setting | 2702 psi (18629.7 kPa) |
| Pump Flow Capacity | 50 gal/min (189 L/min) |
| Raise Time | 6 sec |
| Dump Time | 0.9 sec |
| Lower Time | 3.4 sec |
| Pump Type | Vane type, transmission mounted, directly driven by engine |
