John Deere 244J
Browse All John Deere or Integrated Tool Carrier Models
Contents:
Dimensions
| Length W/ Bucket On Ground | 17.38 ft in (5295 mm) |
| Width Over Tires | 6.07 ft in (1848 mm) |
| Height To Top Of Cab | 8.95 ft in (2725 mm) |
| Wheelbase | 7.06 ft in (2150 m) |
| Ground Clearance | 0.97 ft in (295 mm) |
| Hinge Pin Max Height | 10.54 ft in (3211 mm) |
| Dump Clearance At Max Lift | 8.37 ft in (2550 mm) |
| Max Lift Height | 9.98 ft in (3039 mm) |
| Fork Tine Length | 3.94 ft in (1200 mm) |
| Reach At Max Height And Dump | 3.84 ft in (1170 mm) |
| Length With Out Forks On Ground | 19.05 ft in (5805 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4024T |
| Net Power | 64 hp (47.8 kw) |
| Power Measured @ | 2600 rpm |
| Max Torque | 163 lb ft (221 Nm) |
| Torque Measured @ | 1600 rpm |
| Displacement | 147 cu in (2.5 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 11552.3 lb (5240 kg) |
| Fuel Capacity | 21.2 gal (80 L) |
| Cooling System Fluid Capacity | 2.7 gal (10 L) |
| Engine Oil Capacity | 2.3 gal (8.5 L) |
| Front Diff Fluid Capacity | 1.1 gal (4 L) |
| Rear Diff Fluid Capacity | 1.1 gal (4.1 L) |
| Hydraulic System Fluid Capacity | 15.9 gal (60 L) |
| Turning Radius | 11.5 ft in (3505 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Rear Axle Oscillation | 20 degrees |
| Static Tipping Load - Bucket | 8457 lb (3836 kg) |
| Static Tipping Load - Forks | 6404.5 lb (2905 kg) |
| Tire Size | 365/70R18 |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed Forward | 18.7 mph (30 km/h) |
| Max Speed Reverse | 18.7 mph (30 km/h) |
Hydraulic System
| Pump Type | fixed-displacement gear |
| Relief Valve Setting | 3190 psi (21994.3 kPa) |
| Pump Flow Capacity | 17.1 gal/min (64.4 L/min) |
| Raise Time | 4.9 sec |
| Dump Time | 1.4 sec |
| Lower Time | 4 sec |
Bucket
| Breakout Force | 10792 lb (48.1 kN) |
| Bucket Capacity - Heaped | 1 yd3 (0.8 m3) |
| Bucket Capacity - Struck | 0.9 yd3 (0.7 m3) |
